En stock Producto destacado
KSI-01U
KSI-01U MEANWELL USB interface, galvanic isolated bidirectional access to the KNX bus line, support up to 22..
$0.00USD
4571 en stock
Especificaciones clave
Nombre (Detalles):KSI-01U
Estado (Detalles):New
Stock (Detalles):Yes
Formato (Detalles):Din Rail
Información del proveedor
MEANWELL
Productos: 6448
Normalmente se envía dentro de 2-3 días hábiles
Calidad garantizada
Envío rápido
Soporte técnico
Especificaciones técnicas
| Parámetro | Valor |
|---|---|
| Nombre (Detalles) | KSI-01U |
| Estado (Detalles) | New |
| Stock (Detalles) | Yes |
| Formato (Detalles) | Din Rail |
| Serie (Detalles) | KSI-01U |
| Aprobaciones (Detalles) | EC |
| Subformato (Detalles) | IP20 |
| Ancho (mm) (Detalles) | 36.00 |
| Altura (mm) (Detalles) | 90.00 |
| Aplicaciones (Detalles) | Building automation, Lighting |
| Fabricante (Detalles) | MEAN WELL |
| Tipo de producto (Detalles) | Programmer |
| Aislamiento (V) (Detalles) | 3.750,00 |
| Señal de salida (Detalles) | KNX |
| Conector de entrada (Detalles) | Quick Connector |
| Largo/Fondo (Detalles) | 71.00 |
| Descripción larga (Detalles) | Programmer KNX with USB connection.Interface, for programming with software ETS, EITT the KNX bus.Format ladder to install on a DIN rail.Input range21-30vdc. (KNX bus).5Vdc.bus (USB)..Input signals:KNX.Output signal:KNX.No external power source required additional.Configuration of start service, addressing and parametersKNX.KNX protocol.Operations diagnostic.Supports messages of up to220 bytes.Working temperature: from-5ºCup+45 ° Cof ambient temperature.Dimensions (Length x Width x Height) [mm]:71 x 36 x 90.3 years warrantyManufacturer: MEAN WELL.The KSI-01U is a programmer KNX with USB connectionthat provides two-way access isolated to the line of the KNX bus. Does that network configurations require less time and effort. Is used to access all the disposirivos connected to the KNX bus, including commissioning, addressing, the para meters of the configuration, the functions of diagnosis, visualization, protocol, etcOur programmer KSI-01U serves us to schedule with software ETS, EITT the KNX bus. It also supports long messages up to 220 bytes. Is powered by the KNX BUS and the USB interface so no external power needed.Format ladder to install on a DIN rail, designed for automation applications in buildings, office lighting, lighting for smart homes and luxury villas, and lighting of interior LED, |
| Conector de salida (Detalles) | USB |
| Garantía (Años) (Detalles) | 3,00 |
| País de origen (Detalles) | Netherlands |
Descripción del producto
More details
Características clave
- Calidad de grado industrial
- Cumple con RoHS
- Certificado CE
- Garantía de 1 año
Detalles técnicos
Programmer KNX with USB connection.
Documentos del producto
Hoja de datos
Especificaciones técnicas y datos de rendimiento
Manual de usuario
Guía de instalación y operación
